Technical Data

Important:
Only use adequately protected power cables (min. Ø = 3 x 1.0 mm²).
The required power cable must meet the country's standards.
Only qualified personnel is allowed to perform work on the power cable!

	Important:
	Power cable and connector are not included in the delivery.

DMX: The maximum length of the cable is 350 m (in ideal conditions).

Technical Data
Parameters	4 096 (HTP/LTP)
Operating voltage	100-240 V AC, 50/60 Hz
Net weight	5 kg / 11 lbs
Power	max. 50 VA
Dimensions	240 x 427 x 102 mm / 10 x 17 x 4 in

Outputs grandMA3 onPC fader wing

Number	Connector
1 x	USB 2.0 (type B)
2 x	DMX512-A OUT (5pin XLR female)
1 x	IEC connector
1 x	LED desk light (4pin XLR female)
